SPECSMAIN SPECIFICATIONSNumber of input channels:8 (XY mic capsule, 1-4, A, B)Number of output channels:1 (combined stereo headphone/line)CONNECTORSMIC IN:ZOOM mic connectorINPUT 1-4:XLR jacks (2: HOT)INPUT A/B:XLR/TRS combo jacks (XLR: 2 hot, TRS: TIP hot)USB:USB Micro-B(audio interface, mass storage and Guitar Lab connection functions)Note: Use a USB cable that supports data transfer.Operation using USB bus power is possible.REMOTE:ZOOM BTA-1 or other dedicated wireless adapterLINE OUT:3.5 mm stereo miniPHONE OUT:3.5 mm stereo miniPHANTOM POWER 24 V/ 48 V (independent ON/OFF for INPUTS 1–4, Aand B)RECORDERRecording media:Cards that support SD/SDHC/SDXC specificationsFormats:WAV: 44.1/48/96 kHz, 16/24-bit, mono/stereoMP3: 128, 192, 320 kbpsMaximum simultaneous recording tracks:12 (MIC IN, backup recording, 1-4, A, B, and LR)AUDIO INTERFACEMultitrack mode:44.1/48/96 kHz, 16/24-bit, 12-in/2-outStereo mix mode:44.1/48 kHz, 24-bit, 2-in/2-outTUNERChromatic/Guitar/Bass/Open A/Open D/Open E/Open G/DADGADBuilt-in speaker:400 mW 8O mono speakerDisplay:2.4"" (320×240) full-color touchscreen LCDPower:4 AA batteries (alkaline, NiMH or lithium)AC adapter (ZOOM AD-17): DC 5 V/1AUSB bus powerExternal dimensions :H8: 116.4 mm (W) × 163.3 mm (D) × 48.6 mm (H)XYH-6: 78.9 mm (W) × 60.2 mm (D) × 45.2 mm (H)Weight:H8: 354 gXYH-6: 130 gNote: When using a USB cable designed for recharging, audio interface, SD card reader and Guitar Lab connection functions cannot be used.
